Power Cord Testing Machine

• Polarity-Break over, short circuit, open circuit, dislocation
• Leakage current-Setting Range:0.5, 0, 2.0, 3.0, 5.0, 10mA
• Internal High-Voltage-Output 0— 5KV(500VA) Adjustable
• External High-Voltage-Output 0—

5KV(500VA) Adjustable

• Operating Voltage-220VAC 12A 5060 HZ
• Voltmeter High-voltage-range:0- 5KV
• Resolution-0.5 level
• Insulation Voltage-Output Voltage:DC500V
• Insulation resistance-

Range:2,7,20,50,100,200MΩ

• Voltage withstand time-Timing Range:0.1-99.9/S
• Min time for item-measuring:0.3S
• Wire sensitivity->10pF
• Barometric Pressure-<4>
• OK Product-Automatic printing and

push out, counting, and indicator ON

• NG Product-Automatic model locking, counting,indictor ON and buzzer ringing
• Safeguard-electric leakage, Short circuit ,overheating
• Size(W)730*(D)530*(H)500 (mm)

Weight-68Kg
